Three dashes "---" next to the flight phases indicate that no switch has been
assigned for switching between flight phases. In this case, flight phase 1 HOVER is
automatically selected and marked as the active flight phase (x).
Names are pre-assigned to all four possible flight phases. However, those can be
edited using the + / – button or the central wheel.

Assigning switches for flight phases

At least one of the two switches must be assigned before you can use different
control settings in the flight phases:
Open the Setup main menu.
1.
2. Open the Assign.Switches menu.
3. Select Phases 1-3 and open the parameter.
4. Move switch I to the ON position (* must be visible).
To use all four flight phases a switch must also be assigned to Phase 4.
Phase 4 switch (assign a 2-position switch)
If this switch is in ON position (marked with * during assignment), flight phase 4 is
activated. For helicopters, this flight phase is assigned to "auto-rotation". The
position of the switch for flight phases 1-3 does not have any effect in this case.
If no switch is assigned to Phases 1-3, you can only switch between phase 1 and
4 by operating the Phase 4 switch.
Phases 1-3 switch (assign a 3-position switch)
You can use this switch to activate Phase 1, 2, or 3, provided that the Phase 4
switch is in OFF position.

Disabling / enabling flight phases

You can disable flight phases that have not yet been set. Disabled phases cannot
be activated even if a switch is assigned to them. If the switch is moved to a
position for a disabled flight phase, the operator is alerted by a message
(announcement every minute, for as long as the switch remains in this position).
The active flight phase—marked with an x—cannot be disabled.
Open the Setup main menu.
1.
2. Open the Flight phases menu.
