Flight phase name (e.g. SPEED1)
You can select the designations for the flight phases from a list of 13 pre-set
names (see section 7.2.10.5 "Changing flight phase names" on page 207).
After activating the input field for the name, select a suitable name by pressing
the + / – buttons or by using the central wheel.
Disabled flight phases are shown crossed out.
x
Identifies the active flight phase.
Switch (e.g. 1>)
Switch that is assigned to the flight phase; the arrow indicates if the left (<) or
right (>) switch is associated.
Three dashes "---" indicate that no switch has been assigned for switching
between flight phases.
Slow
Transition time to the next flight phase.
Switching flight phases may involve major surface position changes. Sudden
major changes e.g. to camber-changing flaps or airbrakes make controlling the
model difficult and lead to undesired, hard transitions to the next flight phase.
These problems do not occur when the transition is performed slowly. The
transition is automatically calculated in such a way that all servos move to their
new positions in a synchronized manner and within the selected time frame.
The control commands by the pilot are not slowed down.
Possible range: 0.1 to 6.0 seconds
Pressing REV/CLR
Disables or enables the selected flight phase.
