Tank Drain Assembly

1
2
3
4
5
6
7
8
1. Spray tank
2. Cap screw
3. Lynch pin assembly
4. Flange nut (2 used)
5. Peg mount (2 used)
6. Rubber washer (2 used)
Spray System
9
4
10
11
7. Drain valve
8. Barbed fitting
9. Hose clamp (2 used)
10. Hose
11. R- -clamp
12. Carriage bolt
12
Figure 55
Page 6 - - 50
13
15
14
16
17
18
9
FRONT
RIGHT
13. Drain outlet
14. Plastic seal
15. Ring nut
16. O- -ring
17. Bulkhead nut
18. Elbow fitting
Multi Pro 1200/1250
10
