Boom Bypass
1. Spray tank
2. O- -ring
3. Hosebarb
4. O- -ring
5. Fork
Spray System
14
6
4
3
13
Figure 51
6. Bulkhead nut
7. Bulkhead gasket
8. Bulkhead fitting
9. Adapter
10. Nipple
Page 6 - - 46
11
12
10
9
2
8
7
1
11. Union
12. Elbow
13. Hose clamp
14. Boom bypass hose
5
FRONT
RIGHT
Multi Pro 1200/1250
