Installing the Server

These topics describe how to install the server into an equipment rack using a
rackmount kit.
Note – In this guide, the term rack means either an open rack or a closed cabinet.
"Rack Compatibility" on page 19
■
"Rack Cautions" on page 20
■
"Stabilize the Rack for Installation" on page 21
■
"Mounting the Server Into a 4-Post Rack" on page 22
■
"Mounting the Server Into a 2-Post Rack" on page 42
■
Related Information
"Preparing for Installation" on page 1
■

Rack Compatibility

Check that your rack is compatible with the slide rail options. The optional slide rails
are compatible with equipment racks that meet the following standards.
Item
Structure
Rack horizontal opening and unit
vertical pitch
Distance between front and rear
mounting planes
Requirement
Four-post rack (mounting at both front and rear).
Two-post racks are not compatible.
Conforms to ANSI/EIA 310-D-1992 or IEC 60927
standards. Only M6 tapped or 9.5 mm square are
supported.
Minimum 622 mm and maximum 895 mm
(24.5 in. to 35.25 in.).
19
