Gigabit-Ethernet Ports - Sun Oracle Netra SPARC T3-1 Installation Manual

Pin
1
2
3
4
Related Information
"Back Panel Connectors and Ports" on page 66
■
"Connect Other Data Cables" on page 69
■

Gigabit-Ethernet Ports

Four RJ-45 Gigabit-Ethernet connectors (NET0, NET1, NET2, NET3) can be accessed
from the back panel. The Ethernet interfaces operate at 10 Mbit/sec, 100 Mbit/sec,
and 1000 Mbit/sec.
Pin
1
92 Netra SPARC T3-1 Server Installation Guide • August 2013
Signal Description
Transmit Data +
Transmit Data -
Receive Data +
No Connect
Signal Description
Transmit/Receive Data 0 +
Pin Signal Description
5 No Connect
6 Receive Data -
7 No Connect
8 No Connect
Pin Signal Description
5 Transmit/Receive Data 2 -
