Install The Server (19-Inch, 4-Post Hardmount Rackmount Kit) - Sun Oracle Netra SPARC T3-1 Installation Manual

TABLE:
No.
10
10
10
10
9
12
12
Related Information
"Install the Server (19-Inch, 4-Post Hardmount Rackmount Kit)" on page 24
■
▼ Install the Server (19-Inch, 4-Post Hardmount
Rackmount Kit)
Note – The front-to-back rail spacing must be at least 460 mm (18.11 in.) and not
more than 715 mm (28.15 in.) from the outside face of the front rail to the outside face
of the back rail.
1. Read the Cautions for racks.
See
2. Use four of the supplied M5 x 4.5-mm flathead Phillips screws to secure each of
the hardmount brackets to the sides of the server.
24 Netra SPARC T3-1 Server Installation Guide • August 2013
19-inch, 4-Post Rackmount Screw Kit Contents
Description
M5 x 4.5 mm Phillips flathead screws
M4 x 0.5 mm x 5 mm Phillips panhead
screws
M5 x 12.7 mm screws
M6 x 13 mm screws
M6 square clip nuts
10-32 x 0.5 in. combo head screws
12-24 x 0.5 in. combo head screws
"Rack Cautions" on page
Where Used
8 for hardmount brackets, 2 extra
4-6 for rear mount brackets, 6-4 extra
10 for rack, if appropriate
10 for rack, if appropriate
9 for rack, if appropriate
12 for rack, if appropriate
12 for rack, if appropriate
20.
