Component
CPU
Memory
Removable mass storage
Service processor
TPM support
Front I/O ports
Rear I/O ports
Front panel indicators and
switches
Expansion slots
4 Netra SPARC T3-1 Server Installation Guide • August 2013
Description
SPARC T3, single socket 16-core, 1.6 GHz
DDR3 1066 MHz registered DIMMs with ECC
4 GB and 8 GB DIMM capacities supported
Total x16 DIMMs
Four SFF (2.5 in.) SAS drives
One SATA DVD drive
ASPEED AST2200 BMC running Oracle ILOM 3.x. service processor firmware with
provision for:
• 2D graphics (HD-15 VGA Connector)
• 128 MB SDRAM
• Serial management (RJ-45)
• Network management (10/100Base-T Ethernet RJ-45)
• Complete host remote management including remote KVMS over Ethernet
TCG TPM v1.2 functionality support with an Infineon
SLB 9635
Two USB 2.0 port (Type A)
From the motherboard:
• Four 10/100/1000Base-T Ethernet (RJ-45) with integrated link/speed LEDs
• SER MGT (TIA/EIA-232 serial via RJ-45: Sun/Cisco standard)
• NET MGT 10/100Base-T Ethernet (RJ-45)
• Two USB 2.0 ports (Type A)
• VGA video port (HD-15)
• Optional 10Gb dual ports with XAUI cards
From the PCI mezzanine board:
• DCA relay connection (DB-15)
Provision for the following indicator and switches:
• Power button switch
• Locate button switch with integrated white LED
• System OK LED (Green)
• System fault LED (Amber)
• Alarm LEDs - Critical (Red), Major (Red), Minor (Amber), User (Amber)
• Fan Module Fault LEDs
PCI-Express Generation 2:
• Two full-height / half-length PCI2 2.0 x8 electrical / x16 mechanical slots with
tool-less mechanical fillers
• Three PCIe 2.0 x8 electrical / x8 mechanical low-profile, or one PCIe 2.0 x8
electrical / x8 mechanical low-profile and two XAUI cards (fiber or copper
versions)
