Install The Server (19-Inch, 4-Post Sliding Rail Rackmount Kit) - Sun Oracle Netra SPARC T3-1 Installation Manual

TABLE:
No.
10
10
8
10
12
9
10
12
12
Related Information
"Install the Server (19-Inch, 4-Post Sliding Rail Rackmount Kit)" on page 28
■
▼ Install the Server (19-Inch, 4-Post Sliding Rail
Rackmount Kit)
Note – The front-to-back rail spacing must be at least 392 mm (15.43 in.) and not
more than 863.6 mm (34 in.) from the outside face of the front rail to the outside face
of the back rail.
1. Read the Cautions for racks.
See
2. Use four of the supplied M5 x 4.5 mm flathead Phillips screws to secure each of
the hardmount brackets to the sides of the server.
These hardmount brackets and screws are shipped with the standard server ship
kit, not as part of the sliding rail 19-inch, 4-post rackmount kit.
28 Netra SPARC T3-1 Server Installation Guide • August 2013
19-Inch, 4-Post Sliding Rail Mount Screw Kit Contents
Description
M4 x 0.5 mm x 5 mm Phillips panhead
screws
M6 brass collar screws
M5 panhead screws, nuts, plain
washers and star washers
M5 x 12.7 mm screws
M6 x 13 mm screws
M6 square clip nuts
10–32 collar screws 4 short, 4 long, 2
extra
10-32 x 0.5 in. combo head screws
12-24 x 0.5 in. combo head screws
"Rack Cautions" on page
Where Used
8 for glides, 2 extra
4 for short brackets, 4 for long brackets, 2
extra
8 for slides
10 for rack, if appropriate
10 for rack, if appropriate
9 for rack, if appropriate
8 for racks with 10 to 32 holes, if
appropriate
12 for rack, if appropriate
12 for rack, if appropriate
