600-mm, 4-Post Hardmount Screw Kit Contents
TABLE:
No. Description
12 M5 x 7 SEM screws
10 M5 x 12.7 mm screws
10 M6 x 13 mm screws
9 M6 square clip nuts
12 10-32 x 0.5 in. combo head screws
12 12-24 x 0.5 in. combo head screws
Related Information
"Install the Server (600-mm, 4-Post Hardmount Rackmount Kit)" on page 35
■
▼ Install the Server (600-mm, 4-Post Hardmount
Rackmount Kit)
Note – The front-to-back rail spacing must be at least 392 mm (15.43 in.) and not
more than 504 mm (19.84 in.) from the outside face of the front rail to the outside face
of the back rail.
1. Read the Cautions for racks.
See "Rack Cautions" on page
2. Loosen the two screws at the middle of each adjustable rail so that you can
extend the adjustable rail.
Where Used
8 for side rails, 4 for rear flanges
10 for rack, if appropriate
10 for rack, if appropriate
9 for rack, if appropriate
12 for rack, if appropriate
12 for rack, if appropriate
20.
Installing the Server 35
