▼ Connect a Terminal or Emulator to the
SER MGT Port
●
Connect a terminal or a terminal emulator (PC or workstation) to the service
processor serial management port.
Configure the terminal or terminal emulator with these settings:
9600 baud
■
8 bits
■
No parity
■
1 Stop bit
■
No handshake
■
A null modem configuration is needed, meaning the transmit and receive signals
are reversed (crossed over) for DTE to DTE communications. You can use the
supplied RJ-45 crossover adapters with a standard RJ-45 cable to achieve the null
modem configuration.
Note – When you power on the server for the first time and you do not have a
terminal or terminal emulator (PC or workstation) connected to the service processor
serial management port, you will not see system messages.

▼ Power On the Server for the First Time

Complete the following tasks:
Confirm that you have completed the installation of the server in its rack. See
■
"Installing the Server" on page
Connect a terminal or terminal emulator to the SER MGT port. See
■
Terminal or Emulator to the SER MGT Port" on page
1. (Optional) Connect an Ethernet cable between the server's NET MGT port and
the network to which future connections to the SP and host will be made.
See "Connect the NET MGT Cable" on page
After the initial configuration of the server using the SER MGT port,
communication with the SP and host is usually performed through this Ethernet
interface.
19.
68.
Powering On the Server for the First Time
"Connect a
79.
79
