Item
Clearance depth in front of front
mounting plane
Clearance depth behind front
mounting plane
Clearance width between front and
rear mounting planes
Server dimensions
Related Information
"Rack Cautions" on page 20
■

Rack Cautions

Caution – Equipment Loading. Always load equipment into a rack from the bottom
up so that the rack will not become top-heavy and tip over. Deploy your rack's
antitip bar to prevent the rack from tipping during equipment installation.
Caution – Elevated Operating Ambient Temperature. If the server is installed in a
closed or multi-unit rack assembly, the operating ambient temperature of the rack
environment might be greater than room ambient temperature. Therefore, install the
equipment only in an environment compatible with the maximum ambient
temperature (Tma) specified for the server.
Caution – Reduced Air Flow. Install the equipment in a rack so that the amount of
air flow is adequate for the safe operation of the equipment.
Caution – Mechanical Loading. Mount the equipment in the rack so that the weight
is distributed evenly. A hazardous condition can exist with uneven mechanical
loading.
20 Netra SPARC T3-1 Server Installation Guide • August 2013
Requirement
Distance to front cabinet door is at least 27 mm
(1.06 in.).
Distance to rear cabinet door is at least 900 mm (35.5
in.) with the CMA, or 770 mm (30.4 in.) without the
CMA.
Distance between structural supports and cable
troughs is at least 456 mm (18 in.).
Depth (not including PS handle): 732 mm (28.82 in.).
Width (not including ears): 436.5 mm (17.19 in.).
Height: 129.85 mm (5.11 in.).
