▼ Install the Server (23-Inch, 2-Post Hardmount
Rackmount Kit)
Note – The 23-inch, 2-post rackmount kit supports rack web thicknesses (the width
of the rack post) of 76.20 mm (3 in.), 101.6 mm (4 in.), and 127 mm (5 in.).
1. Read the Cautions for racks.
See "Rack Cautions" on page
2. Using eight of the M5 x 7 SEM screws (four for each side bracket), secure the
side brackets to the sides of the server.
3. Lift the rail guides to the desired height in the rack and, using two screws each,
secure both rail guides to the rack.
The size of the screws varies, depending on your particular rack.
20.
Installing the Server 45
