Mounting the Server Into a 4-Post Rack

These topics provide installation instructions for the 4-post rackmount kits. The
server ships with a 19-inch, 4-post hardmount rackmount kit. You can order two
optional rackmount kits for your specific 4-post rack.
Note – References to left and right are from your viewpoint as you face either the
front or rear of the equipment.
Caution – The server is heavy. Two people are required to lift and mount the server
into a rack enclosure when following these procedures.
Caution – You must install the server into a rack following these instructions. If you
deviate from these instructions when installing the server, your installation will not
be supported.
Description
Mount the server using a 19-inch,
4-post hardmount rackmount kit
(included with the server).
Mount the server using an optional
19-inch, 4-post slide rackmount kit
for 600–800 mm cabinet depths.
Mount the server using an optional
600 mm x 600 mm rackmount kit.
Related Information
"Preparing for Installation" on page 1
■
22 Netra SPARC T3-1 Server Installation Guide • August 2013
Links
"19-Inch, 4-Post Hardmount Rackmount Kit" on
page 23
"Install the Server (19-Inch, 4-Post Hardmount
Rackmount Kit)" on page 24
"19-Inch, 4-Post Sliding Rail Rackmount Kit" on
page 27
"Install the Server (19-Inch, 4-Post Sliding Rail
Rackmount Kit)" on page 28
"600-mm, 4-Post Hardmount Rackmount Kit" on
page 34
"Install the Server (600-mm, 4-Post Hardmount
Rackmount Kit)" on page 35
