4. Using eight of the M4 x 0.5 x 5 mm panhead Phillips screws from the rackmount
kit (four for each side), screw each glide to the side of the server chassis.
5. Lift each short bracket to the desired position at the front of the rack and attach
a short bracket to each of the front rack uprights.
Use two of the brass M6 collar screws and M6 cage nuts (if required), and one
threaded strip, to secure each bracket.
6. Lift each long bracket to the desired position at the rear of the rack and attach a
long bracket to each of the rear rack uprights.
To secure each bracket, use two of the brass M6 collar screws and M6 cage nuts (if
required) and one threaded strip, exactly as you did for the front rack uprights in
the previous step.
30 Netra SPARC T3-1 Server Installation Guide • August 2013
