Install A Server (19-Inch, 2-Post Sliding Rail Rackmount Kit) - Sun Oracle Netra SPARC T3-1 Installation Manual

19-Inch, 2-Post Sliding Rail Mount Screw Kit Contents
TABLE:
No. Description
10 M4 x 0.5 mm x 5 mm Phillips panhead
screws
10 M5 x 12.7 mm screws
12 M6 x 13 mm screws
9 M6 square clip nuts
10 10–32 collar screws, 4 short, 4 long, 2
extra
12 10–32 x 0.5 in. combo head screws
12 12–24 x 0.5 in. combo head screws
Related Information
"Install a Server (19-Inch, 2-Post Sliding Rail Rackmount Kit)" on page 57
■
▼ Install a Server (19-Inch, 2-Post Sliding Rail
Rackmount Kit)
Note – The 19-inch, 2-post sliding rail rackmount kit supports rack web thicknesses
(the width of the rack post) of 76.20 mm (3 in.), 101.6 mm (4 in.), and 127 mm (5 in.).
Note – The front-to-back rail spacing must be at least 392 mm (15.43 in.) and not
more than 863.6 mm (34 in.) from the outside face of the front rail to the outside face
of the back rail.
1. Read the Cautions for racks.
See "Rack Cautions" on page
2. Press in the green button on each slide assembly, and pull the right side and left
side inner glides completely out of the slides.
Where Used
8 for glides, 2 extra
10 for rack, if appropriate
10 for rack, 2 extra
9 for rack, if appropriate
8 for racks with 10-32 holes, if appropriate
12 for rack, if appropriate
12 for rack, if appropriate
20.
Installing the Server 57
