Server Handling Precautions - Sun Oracle Netra SPARC T3-1 Installation Manual

2 Power supply status LEDs: - OK
(output): (green)
- Service Action Required: (amber)
- AC or DC (input power): (green)
3 Alarm port
4 Expansion slot 0 (PCIe 2.0 x8 or XAUI)
5 Expansion slot 3 (PCIe 2.0 x8)
6 Expansion slot 1 (PCIe 2.0 x8 or XAUI)
7 Expansion slot 4 (PCIe 2.0 x8)
8 Expansion slot 2 (PCIe 2.0 x8)
Related Information
"Front Panel Components" on page 13
■

Server Handling Precautions

Caution – Deploy the antitilt bar on the equipment rack before beginning an
installation.
Caution – The server weighs approximately 55 lb (25 kg). Two people are required
to lift and mount this 2U server into a rack enclosure when using the procedures in
this document.
10 SER MGT RJ-45 serial port
11 NET MGT RJ-45 network port
12 Network 10/100/1000 ports (NET0 to
NET3) for host
13 Physical Presence button access hole
14 USB 2.0 ports (USB 0, USB 1)
15 Video connector (HD-15)
16 Grounding studs
Preparing for Installation 15
