6
GPS OPERATION (ADVANCED)

Transmitting D-PRS data

When D-PRS is selected as the GPS TX mode, you
can transmit D-PRS data�
When operating in the D-PRS mode, the following
codes are transmitted to the PC�
D-PRS code is based on APRS
(APRS ® : Automatic Packet Reporting System)

DD-PRS

D-STAR Packet Reporting System (D-PRS) is a mode
that simultaneously sends position data received from
the internal GPS receiver, using the slow speed data
packet space, along with voice audio in the DV mode�
In the Analog mode, you can transmit or receive only
voice audio or data at one time� However, a D-PRS
capable radio can transmit or receive message data
or GPS position data simultaneously when voice is
being transmitted or received� An I-GATE is required
to send position data to the APRS server�
The image of D-PRS
<Using a Repeater>
Voice, Messages, and
D-PRS positions
Voice, Messages, and
D-PRS positions
<Simplex>
Voice, Messages, and
D-PRS positions

DOperating in the D-PRS mode

To transmit D-PRS data, follow the steps below�
For more details, see the pages listed along with the
steps�
1� Enter "MY" (Your own call sign)�
(Basic manual D-STAR GUIDE)
2� Confirm the GPS signal is receiving�
3� Set GPS TX mode to "D-PRS�" (p� 6-14)
4� Set TX information�
L You must set "SSID" and "Symbol�"
([MENU] > GPS > GPS TX Mode > D-PRS)
Complete! You can transmit in the D-PRS mode�
® code�
D-STAR Repeater
Voice, Messages, and
D-PRS positions
I-GATE
↓
NOTE:
• If "GPS select" is set to "Manual," the manually entered
position data in "Manual Position" is changed to the
D-PRS data format to transmit�
([MENU] > GPS > GPS Set > GPS Select)
• Note that if "GPS Auto TX" is set to any other setting than
"OFF," it is transmitted according to the set time�
([MENU] > GPS > GPS Auto TX)
D-PRS positions
APRS server
INTERNET INTERNET
D-PRS positions
TIP: In the D-PRS mode, you can transmit
earthquake or weather information, in addition to
position data�
([MENU] > GPS > GPS TX Mode > D-PRS > TX Format)
TX format of D-PRS
• Position (Mobile/Base):
Used to transmit position data�
• Object: Used to transmit specific position data�
(Contains a time stamp�)
• Item: Used to transmit specific position data�
(Does not contain a time stamp�)
• Weather: Used to transmit weather information�
6-12
Information from
an APRS network
D-PRS
PC
positions
JA3YUA-Z
You can check the
position on a map site!
