www.ti.com
SPIx_SCS
SPIx_ENA
SPIx_CLK
SPIx_SOMI
SPIx_SIMO
MASTER SPI
Figure 4-32. Illustration of SPI Master-to-SPI Slave Connection
Submit Documentation Feedback
TMS320C6727, TMS320C6726, TMS320C6722
Floating-Point Digital Signal Processors
Optional − Slave Chip Select
Optional Enable (Ready)
SPRS268E – MAY 2005 – REVISED JANUARY 2007
SPIx_SCS
SPIx_ENA
SPIx_CLK
SPIx_SOMI
SPIx_SIMO
SLAVE SPI
Peripheral and Electrical Specifications
81
