Table 3-3 lists the options for configuring the SPI1, McASP0, and McASP1 pins. Note that there are
additional finer grain options when selecting which McASP controls the particular AXR serial data pins but
these options are not listed here and can be made on a pin by pin basis.
Table 3-3. Options for Configuring SPI1, McASP0, and McASP1 Data Pins
PERIPHERAL SPI1
McASP0
(max data pins)
McASP1
(max data pins)
PINS AXR0[5]/
SPI1_SCS
AXR0[6]/
SPI1_ENA
AXR0[7]/
SPI1_CLK
AXR0[8]/AXR1[5]/
SPI1_SOMI
AXR0[9]/AXR1[4]/
SPI1_SIMO
Table 3-4 lists the options for configuring the shared EMIF and UHPI pins.
Table 3-4. Options for Configuring EMIF and UHPI (C6727 Only)
PERIPHERAL UHPI
EMIF
PINS EM_D[31:16]/
UHPI_HA[15:0]

3.3 Peripheral Pin Multiplexing Control

While Section 3.2
multiplexing is largely determined on an individual pin-by-pin basis. Typically, each peripheral that shares
a particular pin has internal control registers to determine the pin function and whether it is an input or an
output.
The C672x device determines whether a particular pin is an input or output based upon the following
rules:
The pin will be configured as an output if it is configured as an output in any of the peripherals sharing
the pin.
It is recommended that only one peripheral configure a given pin as an output. If more than one
peripheral does configure a particular pin as an output, then the output value is controlled by the
peripheral with highest priority for that pin. The priorities for each pin are given in
The value input on the pin is passed to all peripherals sharing the pin for input simultaneously.
Submit Documentation Feedback
OPTION 1
5-pin mode 4-pin mode
11 12
4 4
SPI1_SCS SPI1_SCS
SPI1_ENA AXR0[6]
SPI1_CLK SPI1_CLK
SPI1_SOMI SPI1_SOMI
SPI1_SIMO SPI1_SIMO
Multiplexed Address/Data Mode, Fullword, or Non-Multiplexed Address/Data Mode
Half-Word
32-bit EMIF Data
EM_D[31:16]
describes at a high level the most common pin multiplexing options, the control of pin
TMS320C6727, TMS320C6726, TMS320C6722
Floating-Point Digital Signal Processors
CONFIGURATION
OPTION 2 OPTION 3
4-pin mode
12
4
AXR0[5]
SPI1_ENA
SPI1_CLK
SPI1_SOMI
SPI1_SIMO
CONFIGURATION
OPTION 1
SPRS268E – MAY 2005 – REVISED JANUARY 2007
OPTION 4 OPTION 5
3-pin mode disabled
13 16
4 6
AXR0[5] AXR0[5]
AXR0[6] AXR0[6]
SPI1_CLK AXR0[7]
SPI1_SOMI AXR0[8] or AXR1[5]
SPI1_SIMO AXR0[9] or AXR1[4]
OPTION 2
Fullword
16-bit EMIF Data
UHPI_HA[15:0]
Table 3-5.
Device Configurations 31
