4.18.2 PLL Registers Description(s)
Table 4-41 is a list of the PLL registers. For more information about these registers, see the
TMS320C672x DSP Software-Programmable Phase-Locked Loop (PLL) Controller Reference Guide
(literature number SPRU879).
BYTE ADDRESS
0x4100 0000 PLLPID
0x4100 0100 PLLCSR
0x4100 0110 PLLM
0x4100 0114 PLLDIV0
0x4100 0118 PLLDIV1
0x4100 011C PLLDIV2
0x4100 0120 PLLDIV3
0x4100 0138 PLLCMD
0x4100 013C PLLSTAT
0x4100 0140 ALNCTL
0x4100 0148 CKEN
0x4100 014C CKSTAT
0x4100 0150 SYSTAT
