4.9.2 dMAX Peripheral Registers Description(s)
Table 4-3 is a list of the dMAX registers.
BYTE ADDRESS
0x6000 0008 DEPR
0x6000 000C DEER
0x6000 0010 DEDR
0x6000 0014 DEHPR
0x6000 0018 DELPR
0x6000 001C DEFR
0x6000 0034 DER0
0x6000 0054 DER1
0x6000 0074 DER2
0x6000 0094 DER3
0x6000 0040 DFSR0
0x6000 0060 DFSR1
0x6000 0080 DTCR0
0x6000 00A0 DTCR1
N/A DETR
N/A DESR
Submit Documentation Feedback
Table 4-3. dMAX Configuration Registers
REGISTER NAME
Event Polarity Register
Event Enable Register
Event Disable Register
Event High-priority Register
Event Low-priority Register
Event Flag Register
Event Register 0
Event Register 1
Event Register 2
Event Register 3
FIFO Status Register 0
FIFO Status Register 1
Transfer Complete Register 0
Transfer Complete Register 1
Event Trigger Register (Located in C67x+ DSP Register File)
Event Status Register (Located in C67x+ DSP Register File)
TMS320C6727, TMS320C6726, TMS320C6722
Floating-Point Digital Signal Processors
SPRS268E – MAY 2005 – REVISED JANUARY 2007
DESCRIPTION
