4.12.2 UHPI Peripheral Registers Description(s)
Table 4-11 is a list of the UHPI registers.
BYTE ADDRESS
0x4000 0008 CFGHPI
0x4000 000C CFGHPIAMSB
0x4000 0010 CFGHPIAUMB
0x4300 0000 PID
0x4300 0004 PWREMU
0x4300 0008 GPIOINT
0x4300 000C GPIOEN
0x4300 0010 GPIODIR1
0x4300 0014 GPIODAT1
0x4300 0018 GPIODIR2
0x4300 001C GPIODAT2
0x4300 0020 GPIODIR3
0x4300 0024 GPIODAT3
0x4300 0028 Reserved
0x4300 002C Reserved
0x4300 0030 HPIC
0x4300 0034 HPIAW
0x4300 0038 HPIAR
0x4300 003C Reserved
0x4300 0040 Reserved
Submit Documentation Feedback
Table 4-11. UHPI Configuration Registers
REGISTER NAME
Device-Level Configuration Registers Controlling UHPI
UHPI Configuration Register
Most Significant Byte of UHPI Address
Upper Middle Byte of UHPI Address
UHPI Internal Registers
Peripheral ID Register
Power and Emulation Management Register
General Purpose I/O Interrupt Control Register
General Purpose I/O Enable Register
General Purpose I/O Direction Register 1
General Purpose I/O Data Register 1
General Purpose I/O Direction Register 2
General Purpose I/O Data Register 2
General Purpose I/O Direction Register 3
General Purpose I/O Data Register 3
Reserved
Reserved
Control Register
Write Address Register
Read Address Register
Reserved
Reserved
TMS320C6727, TMS320C6726, TMS320C6722
Floating-Point Digital Signal Processors
SPRS268E – MAY 2005 – REVISED JANUARY 2007
DESCRIPTION
Peripheral and Electrical Specifications 59
