4.5 Parameter Information

4.5.1 Parameter Information Device-Specific Information
42
4.0 pF
A. The data sheet provides timing at the device pin. For output timing analysis, the tester pin electronics and its
transmission line effects must be taken into account. A transmission line with a delay of 2 ns or longer can be used to
produce the desired transmission line effect. The transmission line is intended as a load only. It is not neccessary to
add or subtract
Input requirements in this data sheet are tested with an input slew rate of < 4 Volts per nanosecond (4 V/ns) at the
device pin.
4.5.1.1 Signal Transition Levels
All input and output timing parameters are referenced to 1.5 V for both "0" and "1" logic levels.
Figure 4-2. Input and Output Voltage Reference Levels for AC Timing Measurements
All rise and fall transition timing parameters are referenced to V
V MAX and V
OL OH
Figure 4-3. Rise and Fall Transition Time Voltage Reference Levels
4.5.1.2 Signal Transition Rates
All timings are tested with an input edge rate of 4 Volts per nanosecond (4 V/ns).
Submit Documentation Feedback
Tester Pin Electronics
3.5 nH
Transmission Line
Z0 = 50
(see note)
1.85 pF
the transmission line delay
Figure 4-1. Test Load Circuit for AC Timing Measurements
MIN for output clocks.
TMS320C6727, TMS320C6726, TMS320C6722
Floating-Point Digital Signal Processors
SPRS268E – MAY 2005 – REVISED JANUARY 2007
Data Sheet Timing Reference Point
(2 ns or longer) from
MAX and V
IL
V = V
ref
V = V
ref
Peripheral and Electrical Specifications
Output
Under
Test
Device Pin
(see note)
the data sheet timings.
V = 1.5 V
ref
MIN for input clocks,
IH
MIN (or V MIN)
IH OH
MAX (or V MAX)
IL OL
