Removing and Installing the System Cover

Removing the System Cover

The server system must be operated with the system cover in place to ensure proper
cooling. You will need to remove the top cover to add or replace components inside of the
server. Before removing the top cover, power down the server and unplug all peripheral
devices and the AC power cable(s).
Note: A nonskid surface or a stop behind the server system may be needed to prevent the server
system from sliding on your work surface.
To remove the server system cover, follow these steps:
1. Remove the safety screw if it is installed (see letter "A" in
2. While holding in the blue button at the top of the server system in (see letter "B" in
Figure
3. Insert your finger in the notch (see letter "D" in
upward to remove it.
48
30), slide the top cover back until it stops (see letter "C" in
D
B

Figure 30. Removing the Server System Cover

Intel
Figure
A
®
Server System SR2600UR/SR2625UR Service Guide
Figure 30).
Figure 30).
30) and lift the cover
C
AF002954
