2.5-inch Fixed Hard Disk Drive (HDD) Kit: ASR2600FXDRV
The tape drive and the 2.5-inch fixed hard drives are not hot-swappable. The system
power must be turned off to insert or remove the drives. The sixth hard drive is hot-
swappable. For instructions on installing the drives, see the following sections:
•
"Installing a Tape Drive" on page 84
•
"Installing a Sixth Hard Disk Drive (Intel® Server System SR2600UR only)" on
page 87
•
"Installing the 2.5-Inch Fixed Hard Disk Drives" on page 90
Control Panel
The Intel
•
Standard Control Panel
•
Intel
Standard Control Panel
The following diagram shows the features available on the standard control panel..
Callout
A.
B.
C.
Intel® Server System SR2600UR/SR2625UR Service Guide
®
Server System SR2600UR supports the following types of control panels:
®
Local Control Panel
Feature
NIC 2 Activity LED
Continuous green light indicates a link between the system and
the network to which it is connected.
NIC 1 Activity LED
Blinking green light indicates network activity.
Power/Sleep Button
Powers on/off the system.
If enabled by an ACPI-compliant operating system, this button
functions as a Sleep button and puts the system in an ACPI sleep
state.
A
B
C
D
E
F
L
K
J
G
H
I
AF000030
Function
23
