Replacing The Control Panel (Intel Server System Sr2600Ur Only); Figure 117. Removing Standard Control Panel Module From The Server System - Intel SR2625UR - Server System - 0 MB RAM Service Manual

Replacing the Control Panel (Intel
SR2600UR only)
The steps for replacing the standard control panel and the Intel
®
Intel Server System SR2600UR are nearly identical. Use this procedure for both
varieties of the control panel. Where necessary, differences between the two control
panels are noted.
Your server must be operated with a control panel installed.
Caution: The control panel is NOT hot-swappable. Before removing or replacing the control panel,
you must first take the server out of service, turn off all peripheral devices connected to
the system, turn off the system by pressing the power button, and unplug the AC power
cord from the system or wall outlet.
To replace the control panel, follow these steps:
1. Press the latch at the back of the control panel and push forward to release it (see
letter "A" in
2. Slide the control panel out through the front of the server system (see letter "B" in
Figure

Figure 117. Removing Standard Control Panel Module from the Server System

3. Slide the replacement control panel into the server system (see letter "A" in
Figure
®
Intel Server System SR2600UR/SR2625UR Service Guide
Figure 117).
117).
Locking
Lever
A
118) until it clicks into place (see letter "B" in
®
Server System
B
®
Local Control Panel in
AF002983
Figure 118).
123
