Figure 116. Removing The Power Distribution Module - Intel SR2625UR - Server System - 0 MB RAM Service Manual

8. Lift the module from the server system (see letter "B" in
A
9. Set the replacement power supply distribution module into the server system and
screw the module into place.
10. Install the hot-swap power supply/supplies. For instructions, see
Power Supply" on page
11. Connect all power cables to the server board.
12. Install the fan module assembly. For instructions, see
page
13. Install the large air baffle. For instructions, see
page
14. Install the processor air duct. For instructions, see
Duct" on page
15. Install the PCI riser assembly. For instructions, see
Assembly" on page
122
B
A

Figure 116. Removing the Power Distribution Module

121.
128.
70.
57.
51.
"Installing the Large Air Baffle" on
"Installing the Processor Air
"Installing the PCI Riser
®
Intel Server System SR2600UR/SR2625UR Service Guide
Figure 116).
AF002982
"Replacing the
"Replacing a Fan Module" on
