Installing a Sixth Hard Disk Drive (Intel
SR2600UR only)
To install a sixth hard disk drive into Intel
system must meet the following requirements:
•
You must purchase the sixth SAS/SATA Hard Disk Drive (HDD) kit, order number
ASR2500SIXDRV.
•
You must purchase an additional 3.5-inch hard disk drive.
After purchasing the sixth SAS/SATA Hard Disk Drive (HDD) kit and the 3.5-inch hard
disk drive, use the following instructions to install the hard drive.
1. Remove the drive tray from the server system by pressing the blue release lever
(see letter "A" in
out from the front of the system (see letter "B" in
®
Intel Server System SR2600UR/SR2625UR Service Guide
®
Server System SR2600UR/SR2625UR, your
Figure 76) and pushing it forward to release it and then sliding it
A
B

Figure 76. Removing the Drive Tray

®
Server System
Figure 76.
AF003029
87
