Jumper Name
D. Password Clear (J1E8)
E. BIOS Recover (J1D4)
Front of Intel

Peripheral Devices

The Intel
drives, a tape drive, a USB floppy drive, CD-ROM drive, or DVD-ROM drive. The drives
must be purchased separately. The following figure shows the available options.
.
Intel® Server System SR2600UR/SR2625UR Service Guide
If pins 2-3 are jumpered, administrator and user passwords are
cleared within five to ten seconds after the system is powered on.
These pins should be jumpered on 1-2 for normal system
operation.
If pins 2-3 are jumpered, the system can only boot from EFI-
bootable recovery media with the recovery BIOS image. The main
system BIOS will not boot. These pins should be jumpered on 1-2
for normal system operation.

Figure 10. Configuration Jumpers

®

Server System SR2600UR

®
Server System SR2600UR provides locations and hardware for installing hard
A
E
A. Slimline Optical Drive Bay
B. Tape Drive Filler Panel
C. Flex Bay - Sixth Hard Disk Drive or Tape Drive or two fixed
2.5-inch Hard Disk Drives (Optional)
D. Hard Disk Drive Bays
E. Hard Disk Drive to Floppy Drive Conversion Bay (Optional)

Figure 11. Optional Peripherals

Jumper Purpose
B
D C
TP02126
