Hot-Swap SAS/SATA Backplane (Intel
SR2600UR only)
The backplane serves as an interface between the midplane board and the system drives.
The following diagrams show the location for each connector found on the backplane.
A.
Slimline Interposer Card Connector
B.
USB Floppy Connector
34
A
B
Figure 19. Hot-Swap SAS/SATA Backplane Components (Front View)
®
D
C.
Control Panel Connector
D.
SAS/SATA Hot-swap Connectors
Intel® Server System SR2600UR/SR2625UR Service Guide
Server System
C
AF000045
