7. Align the holes in the drive to the holes in the drive carrier and attach it to the
carrier using the four screws that were attached to the plastic retention device (see
letter "B" in
8. With the black lever held in the fully open position, slide the hard disk assembly
into the server system and push all the way until it clicks (see letter "A" in
Figure
9. Close the lever to lock the drive assembly into place (see letter "B" in

Removing a Hot-swap SAS/SATA Hard Disk Drive

To remove a hot-swap SAS/SATA hard disk drive from Intel
follow these steps:
1. Press in on the green latch at the front of the hard drive carrier.
2. Pull out on the black lever to slide the carrier out from the server system.
76
Figure 61).
B

Figure 61. Installing Hard Drive into Carrier

62).
B

Figure 62. Installing Drive Assemby into the Server System

Intel
A
AF002988
A
AF002989
®
Server System SR2600UR/SR2625UR Service Guide
Figure
®
Server System SR2625UR,
62).
