Replacing a PCI Riser Card

Caution: PCI riser cards are NOT hot-swappable. Before removing or replacing the riser card, you
must first take the server out of service, turn off all peripheral devices connected to the
system, turn off the system by pressing the power button, and unplug the AC power cord
from the system or wall outlet.
Note: To eliminate the possibility of installing the replacement connector on the wrong side of
the PCI riser assembly, replace one connector at a time.

Removing a PCI Riser Card

To remove a PCI Riser Card, follow these steps:
1. Disconnect any cables attached to any add-in cards.
2. Remove the PCI riser assembly. For instructions, see
Assembly" on page
3. Remove any add-in cards from the PCI riser card. For instructions, see
a PCI Add-in Card" on page
4. Push back on the blue release lever at the end of the riser card (see letter "A" in
Figure
5. While holding the lever back, slide the card firmly in the direction shown to
disengage the card from the riser pins (see letter "B" in
the riser assembly (see letter "C" in

Figure 34. Removing the PCI Riser Card from the Server System (Full-height Side)

6. Install the replacement riser card, if desired. For instructions, see
Riser Card into the Server System" on page
52
50.
55.
34).
Riser Retention Pin
Intel
"Removing the PCI Riser
Figure
Figure 34).
A
B
C
r C a r
R i s e
53.
®
Server System SR2600UR/SR2625UR Service Guide
"Removing
34) and remove from
d
AF003012
"Installing PCI
