Installing and Removing the I/O Expansion Module

Installing the I/O Expansion Module

To install the I/O expansion module, follow these steps:
1. Remove the PCI riser assembly. For instructions, see
Assembly" on page
2. Remove the processor air duct. For instructions, see
Duct" on page
3. Squeeze the sides of the I/O expansion module filler panel(s) to disengage it from
the server system back panel and remove it (see letter "A" in
Note: If you are installing an I/O expansion module that uses only one slot, remove the filler
panel only from the slot shown so that the module can be attached to I/O connector 1. Do
not remove the filler panel from the second slot.
4. Attach the standoffs to the server board by pressing to the holes (see letter "B" in
Figure
Note: For the 1-socket expansion module, install the three standoffs shown in gray. For the 2-
scoket expansion module, also install the fourth standoff shown in red.
5. Position the I/O expansion module over the server board as shown in
96
B

Figure 87. Installing the Filler Panels

50.
56.
88).
Intel
A
"Removing the PCI Riser
"Removing the Processor Air
®
Server System SR2600UR/SR2625UR Service Guide
AF003039
Figure 88).
Figure 88.
