Table 2. Intel Server System Sr2600Ur/Sr2625Ur Feature Summary - Intel SR2625UR - Server System - 0 MB RAM Service Manual

Table 2. Intel
Peripheral Interfaces
Video
LAN
Expansion Capabilities
Hard Drives
Peripherals
10
®
Server System SR2600UR/SR2625UR Feature Summary
Feature
External connections:
•
Four USB 2.0 connectors (back)
•
One USB 2.0 connector (front)
•
RJ-45 serial Port A connector
•
Two RJ-45 10/100/1000 Mb Network connections
•
DB-15 video connector (front and back)
Internal connections:
•
One USB 2x5 pin header, which supports two USB 2.0 ports
•
One low-profile USB 2x5 pin header to support low-profile USB
solid state drives
•
One DH-10 serial Port B header
•
Six Serial ATA II connectors
•
Two I/O module connectors
•
One RMM3 connector to support an optional Intel
Management Module 3
•
SATA Software RAID 5 Activation Key connector
•
One SSI-EEB-compliant front panel header
•
One SSI-EEB-compliant 24-pin main power connector
•
One SSI-compliant 8-pin CPU power connectors
•
One SSI-compliant power supply SMBus connector
On-board Server Engines* LLC Pilot II controller with
•
Integrated 2D Video Controller
•
32 MB DDR2 Memory
Two 10/100/1000 ports provided by Intel
The following riser card options are available:
•
Three full-height PCI Express* slots (passive)
•
Two full-height PCI-X slots with an on-board PXH bridge chip +
one full-height and two low-profile PCI Express* slots (active)
•
Five full-height PCI Express* slots (active)
•
Intel
–
–
•
Intel
–
–
•
Intel
levels 0/1/10
•
Optional support for SW RAID 5 with activation key
•
Slimline bay for slimline SATA optical drive
•
"PCI riser card bracket
Description
®
Server System SR2600UR:
Five 3.5-inch hot-swap SATA/SAS hard drives
Flex bay for sixth 3.5-inch hot-swap SATA/SAS hard drive or
a 3.5-inch tape drive or two fixed 2.5-inch hard drives
®
Server System SR2625UR:
Eight 2.5-inch hot-swap SATA/SAS hard drives
Flex bay for two additional fixed 2.5-inch hard drives or 3.5-
inch tape drive
®
Embedded Server RAID Technology II with SW RAID
Intel® Server System SR2600UR/SR2625UR Service Guide
®
Remote
®
82575 PHYs
