Figure 9. Server Board Connector And Component Locations - Intel SR2625UR - Server System - 0 MB RAM Service Manual

®
A. 280-pin Intel Adaptive Slot
D. Processor 1 Socket
G. System Status LED
J. Processor 1 DIMM slots
M. CPU 2 Fan Header
P. Front Panel Connector
S. Main Power Connector
V. USB Header
Y. LCP IPMB Header
BB. SATA Connectors
EE. Serial Port B Header
Intel® Server System SR2600UR/SR2625UR Service Guide
B. POST Code Diagnostic LEDs
E. Back Panel I/O Ports
H. Memory 1 Fan Header
K. Processor 2 DIMM slots
N. Memory 2 Fan Header
Q. Fan Board Connector
T. Power Supply SMBus
Connector
W. Low-profile USB Solid State
Drive Header
Z. SATA RAID 5 Key Header
CC. I/O Module Mezzanine
Connector 2

Figure 9. Server Board Connector and Component Locations

®
C. Intel RMM3 Header
F. System Identification LED
I. CPU 1 Fan Header
L. Processor 2 Socket
O. Bridge Board Connector
®
(Intel Server Chassis)
R. 2x4 Power Connector
U. System 2 Fan Header
X. System 1 Fan Header
AA. SGPIO Header
DD. I/O Module Mezzanine
Connector 1
