Figure 51 Checking Node World Wide Name
Figure 52 Monitoring ungroup progress
Figure 53 Checking disk group status

Removing a disk

CAUTION:
Rotating media can make the disk drive difficult to handle. To avoid dropping and damaging the disk
drive, wait approximately 30 seconds for the media to stop rotating before removing the drive from
the enclosure.
1.
Push in the red wine-colored ejector push button (1,
down to the full open position.
2. Pull the disk drive part way out of the enclosure (3) and wait for the media to stop spinning.
3. When the media has stopped spinning, remove the disk drive from the enclosure.
HP StorageWorks 4x00/6x00/8x00 Enterprise Virtual Array user guide
Figure 54) and pull the release lever (2)
