Removing A Battery; Installing A Battery; Battery Status Indicators - HP StorageWorks 6100 - Enterprise Virtual Array User Manual

Figure 39 Battery status indicators
1. Status indicator
3. Battery 0

Removing a battery

1.
Remove the front panel (1,
enclosure.
2.
While moving the battery mounting latch (2,
enclosure (3). Support the battery with both hands as it is removed.
2
Figure 40 Removing a battery

Installing a battery

Position the battery as high in the slot as possible, then slide the battery into the enclosure (1,
41) until it is fully seated and the mounting latch engages (2).
108 Customer replaceable units
Figure 40) by grasping the panel at each end pulling it off the
3
2. Fault indicator
4. Battery 1
Figure 40 ) to the right, pull the battery out of the
1
0180a
Figure
