• 1.2. is the voltage sensor element type
• 1.3. is the current sensor element type number
• en. is the sensor element number
• ec is the error code
Table 43 lists the location of the power supply voltage and current sensors.
Table 43 Voltage and current sensor locations
Sensor
01.
02.
03.
04.
Use HP Command View EVA to view the voltage and current error thresholds for both +5 VDC and
+12 VDC power supplies.
1.2.en.01 NONCRITICAL condition—High voltage
This condition report indicates that an element voltage is approaching, but has not reached, the high
voltage CRITICAL threshold. Continued operation under these conditions may result in a CRITICAL
condition. This condition report remains active until the problem is corrected.
To correct this problem, record all six characters of the condition report, then contact your HP-authorized
service representative.
1.2.en.02 CRITICAL condition—High voltage
This condition report indicates that an element voltage has reached the high voltage CRITICAL threshold.
This report remains active until the problem is corrected.
To correct this problem, record all six characters of the condition report, then contact your HP-authorized
service representative.
1.2.en.03 NONCRITICAL condition—Low voltage
This condition report indicates that an element voltage is approaching, but has not reached, the low
voltage CRITICAL threshold. Continued operation under these conditions may result in a CRITICAL
condition. This condition report remains active until the problem is corrected.
To correct this problem, record all six characters of the condition report, then contact your HP-authorized
service representative.
1.2.en.04 CRITICAL condition—Low voltage
This condition report indicates that an element voltage has reached the low voltage CRITICAL threshold.
This condition report remains active until the problem is corrected.
To correct this problem, record all six characters of the condition report, then contact your HP-authorized
service representative.
HP StorageWorks 4x00/6x00/8x00 Enterprise Virtual Array user guide
Sensor Element Location
Power Supply 1 +5 VDC
Power Supply 1 +12 VDC
Power Supply 2 +5 VDC
Power Supply 2 +12 VDC
163
