2.
Press to display the last fault information.
The first line of the TC display contains the eight-character TC error code and the two-character
IDX (index) code. The IDX is a reference to the location in the TC array that contains this error.
The second line of the TC display identifies the affected parameter with a two-character parameter
number (0–30), the eight-character parameter code affected, and the parameter code number.
3.
Press to return to the Last Fault menu.

Displaying Detailed Information

The Detail View menu lets you examine detailed fault information stored in the Last Termination Event
Array (LTEA). This array stores information for the last 32 termination events.
Complete the following procedure to display the LTEA information about any of the last 32 termination
events:
1. When the Fault Management display is active (flashing), press
The LTEA selection menu is active (LTEA 0 is displayed).
2. Press or
3.
Press to observe data about the selected error.

Interpreting fault management information

Each version of HP Command View EVA includes an ASCII text file that defines all the codes that the
authorized service representative can view either on the GUI or on the OCP.
IMPORTANT:
This information is for the exclusive use of the authorized service representative.
The file name identifies the controller model, file type, XCS baselevel id, and XCS version. For example,
the file name hsv210_event_cr08d3_5020.txt provides the following information:
• hsv210_—The EVA controller model number
• event_—The type of information in the file
• w010605_—The base level build string (the file creation date).
• 01—The creation year
• 06—The creation month
• 05—The creation date
• 5020—The XCS version
Table 44 describes types of information available in this file.
Table 44 Controller event text description file
Information type
Event Code
Termination Code (TC)
to increment to a specific error.
This hexadecimal code identifies the reported event type.
This hexadecimal code specifies the condition that generated the termin-
ation code. It might also define either a system or user initiated corrective
action.
HP StorageWorks 4x00/6x00/8x00 Enterprise Virtual Array user guide
to select the Detail View menu.
Description
