IBM AIX configuration

Requirements

• Switch zoning or controller level SSP must be used to ensure each single path HBA has an exclusive
path to its LUNs.
• Single path HBA server can be in the same fabric as servers with multiple HBAs.
• Single path HBA server cannot share LUNs with any other HBAs.
• In the use of snapshots and snapclones, the source virtual disk and all associated snapshots and
snapclones must be presented to the single path hosts that are zoned with the same controller. In
the case of snapclones, after the cloning process has completed and the clone becomes an ordinary
virtual disk, you may present that virtual disk as you would any other ordinary virtual disk.
• HBA must be properly configured to work in a single HBA server configuration. The single path
adapter driver from the AIX 2.0B EVA Kit should be installed: PC1000.image.

HBA configuration

• Host 1 is a single path HBA host.
• Host 2 is a dual HBA host with multi-pathing software.
See Figure 84.

Risks

• Single path failure may result in loss of data accessibility and loss of host data that has not been
written to storage.
• Controller shutdown results in loss of data accessibility and loss of host data that has not been
written to storage.
NOTE:
For additional risks, see

Limitations

• HP Continuous Access EVA is not supported with single path configurations.
• Single path HBA server is not part of a cluster.
• Booting from the SAN is not supported.
Table 62 on page 205.
HP StorageWorks 4x00/6x00/8x00 Enterprise Virtual Array user guide 199
