Limitations; Linux (32-Bit) Configuration; Requirements; Netware Configuration - HP StorageWorks 6100 - Enterprise Virtual Array User Manual

NOTE:
For additional risks, see

Limitations

• HP Continuous Access EVA is not supported with single-path configurations.
• Single path HBA server is not part of a cluster.
• Booting from the SAN is not supported on single path HBA servers.
Figure 81 NetWare configuration
1 Network interconnection
2 Single HBA server
3 Dual HBA server
4 Management server

Linux (32-bit) configuration

Requirements

• Switch zoning or controller level SSP must be used to ensure each single path HBA has an exclusive
path to its LUNs.
• All nodes with direct connection to a disk must have the same access paths available to them.
Table 60 on page 204.
2
5
HP StorageWorks 4x00/6x00/8x00 Enterprise Virtual Array user guide
1
3
6
8
7
5 SAN switch 1
6 SAN switch 2
7 Controller A
8 Controller B
4
26434a
195
