Disk drive status displays

The disk drive status indicators can assume three states: on, off, or flashing. The status indicators states
for operational drive status are shown in
indicator states.
Table 9 Operational disk drive status indications
Activity
Flashing
On
Flashing
Flashing
Table 10 Non-operational disk drive status indications
Activity
On
On

Disk drive blank

To maintain the proper enclosure air flow, a disk drive or a disk drive blank must be installed in each
drive bay. The disk drive blank maintains proper airflow within the disk enclosure.
The green status indicator is on when the disk drive is online and operating
normally. This indicator will be off in the following situations:
• There is no controller on the bus.
• +5.1 VDC is not available.
• The drive is not properly installed in the enclosure.
This amber status indicator is on when there is a disk drive failure. Depending
on the host controller, this indicator may flash when the controller detects an error
condition.
The amber status indicator flashes in synchronization with the other two status
indicators in response to the EMU locate command.
Table
Online Fault
On Off
On Off
Flashing Flashing
On Off
Online Fault
On On
Off Flashing
HP StorageWorks 4x00/6x00/8x00 Enterprise Virtual Array user guide
Description
9. See Table 10 for the non-operational drive status
Initial startup.
The drive is online but is not being accessed.
The drive is being located.
The drive is operational and active.
Indicates no connection or the controllers are offline.
Recommended corrective actions:
1. Check power supplies for proper operation.
2. If defective, replace disk drive.
Indicates disk drive error/not active. Recommended
corrective actions:
1. Verify FC loop continuity.
2.
Replace disk drive.
