Sensor
08.
09.
The following sections list the temperature condition reports and the default temperature thresholds.
Use HP Command View EVA to view the temperature sensor ranges for the disk drives, EMU, and
power supplies.
0.4.en.01 NONCRITICAL condition—High temperature
This condition report indicates that an element temperature is approaching, but has not reached, the
high temperature CRITICAL threshold. Continued operation under these conditions may result in a
CRITICAL condition. This condition report remains active until the problem is corrected.
Complete the following procedure to correct this problem.
1.
Record all six characters of the condition report.
2.
Ensure that all elements are properly installed to maintain proper air flow.
3.
Ensure that nothing is obstructing the air flow at either the front of the enclosure or the rear of
the blower.
4. Ensure that both blowers are operating properly (the indicators are on) and neither blower is
operating at high speed.
5. Verify that the ambient temperature range is +10° C to +35° C (+50° F to +95° F). Correct the
ambient conditions.
6. Observe the EMU to ensure the error is corrected.
7. If unable to correct the problem, contact your authorized service representative.
0.4.en.02 CRITICAL condition—High temperature
This condition report indicates that an element temperature is above the high temperature CRITICAL
threshold. Continued operation under these conditions may result in element failure and may reduce
an element MTBF. This condition report remains active until the problem is corrected.
Complete the following procedure to correct this problem.
1.
Record all six characters of the condition report.
2.
Ensure that all elements are properly installed to maintain proper air flow.
3.
Ensure that nothing is obstructing the air flow at either the front of the enclosure or the rear of
the blower.
4. Ensure that both blowers are operating properly (the indicators are on) and neither blower is
operating at high speed.
5. Verify that the ambient temperature range is +10° C to +35° C (+50° F to +95° F). Adjust as
necessary.
6. Observe the EMU to ensure the error is corrected.
7. If unable to correct the problem, contact your authorized service representative.
Sensor location
Drive Bay 5
Drive Bay 6
HP StorageWorks 4x00/6x00/8x00 Enterprise Virtual Array user guide
Sensor
17. Drive Bay 14
Sensor location
153
