Rack Airflow Requirements

The following requirements must be met to ensure adequate airflow and to prevent damage to the
equipment:
• If the rack includes closing front and rear doors, allow 830 square inches (5,350 sq cm) of hole
evenly distributed from top to bottom to permit adequate airflow (equivalent to the required 64
percent open area for ventilation).
• For side vented components, the clearance between the installed rack component and the side
panels of the rack must be a minimum of 2.75 inches (7 cm).
• Always use blanking panels to fill all empty front panel U-spaces in the rack. This ensures proper
airflow. Using a rack without blanking panels results in improper cooling that can lead to thermal
damage.

Configuration Standards

EVA configurations are designed considering cable length, configuration CG, serviceability and
accessibility, and to allow for easy expansion of the system. If at all possible, it is best to configure
non HP cabinets in a like manner.

Environmental and operating specifications

This section identifies the product environmental and operating specifications.
NOTE:
Further testing is required to update the information in Tables 45-47. Once testing is complete, these
tables will be updated in a future release.

Power requirements

The following tables list the wattage and BTU/hour power requirements for the three supported
operating voltages.
NOTE:
Failover amperage can be estimated at approximately 90% of operational amperage listed.
Table 46 208V Wattage and BTU/Hour
Enclos-
ures
Amps
12
11
10
EVA4x00
VA Watts BTU/h
HP StorageWorks 4x00/6x00/8x00 Enterprise Virtual Array user guide
EVA6x00
A m p s VA Watts BTU/h
EVA8x00
Amps VA Watts BTU/h
24.5 5104 4920 16789
22.0 4578 4414 15060
20.1 4188 4037 13775
175
