Example Configurations
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m
-----------------------
fabric distribution disabled
Last Action
Last Action Result
Last Action Failure Reason : None
Inter-VSAN NAT mode status
--------------------------
FCID-NAT is disabled
License status
-----------------
IVR is running based on the following license(s)
ENTERPRISE_PKG
Enable CFS distribution.
Step 3
mds# config t
Enter configuration commands, one per line.
mds(config)# ivr distribution
Manually configure the IVR VSAN-topology. In
Step 4
(MDS1 and MDS2) are members of VSANs 1 and 4. The other two switches (MDS3 and MDS4) are
members of VSANs 2, 3, and 4.
mds(config)# ivr vsan-topology database
mds(config-ivr-topology-db)# autonomous-fabric-id 1 switch-wwn 20:00:00:05:40:01:1b:c2
vsan-ranges 1,4
mds(config-ivr-topology-db)# autonomous-fabric-id 1 switch-wwn 20:02:00:44:22:00:4a:08
vsan-ranges 1,4
mds(config-ivr-topology-db)# autonomous-fabric-id 1 switch-wwn 20:00:00:44:22:02:8a:04
vsan-ranges 2-4
mds(config-ivr-topology-db)# autonomous-fabric-id 1 switch-wwn 20:00:00:44:22:40:aa:16
vsan-ranges 2-4
mds(config-ivr-topology-db)# exit
mds(config)#
Step 5 Verify the configured VSAN topology.
Note
mds(config)# do show ivr vsan-topology
AFID
--------------------------------------------------------------
1
1
1
1
Total:
Current Status: Inter-VSAN topology is INACTIVE
Activate the configured VSAN topology.
Step 6
mds(config)# ivr vsan-topology activate
Step 7 Verify the activation.
mds(config)# do show ivr vsan-topology
Cisco MDS 9000 Family CLI Configuration Guide
23-40
: None
: None
The configured topology has not yet been activated—as indicated by the
the column.
Active
SWITCH WWN
20:00:00:05:40:01:1b:c2 *
20:00:00:44:22:00:4a:08
20:00:00:44:22:02:8a:04
20:00:00:44:22:40:aa:16
4 entries in active and configured IVR VSAN-Topology
End with CNTL/Z.
Figure 23-1, two of the four IVR-enabled switches
Active Cfg. VSANS
no yes 1,4
no yes 1,4
no yes 2-4
no yes 2-4
Chapter 23 Configuring Inter-VSAN Routing
status displayed in
no
OL-18084-01, Cisco MDS NX-OS Release 4.x
