Chapter 30 Advanced Features and Concepts
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m
•
The number of pending fctimer configuration operations cannot be more than 15. At that point, you must
Note
commit or abort the pending configurations before performing any more operations.

Displaying Configured fctimer Values

Use the show fctimer command to display the configured fctimer values (see Examples
30-13).
Example 30-12 Displays Configured Global TOVs
switch# show fctimer
F_S_TOV
----------------------------------------
5000 ms
The F_S_TOV constant, though not configured, is displayed in the output of the show fctimer command.
Note
Example 30-13 Displays Configured TOVs for a Specified VSAN
switch# show fctimer vsan 10
vsan no.
-------------------------------------------------
10

World Wide Names

The world wide name (WWN) in the switch is equivalent to the Ethernet MAC address. As with the MAC
address, you must uniquely associate the WWN to a single device. The principal switch selection and
the allocation of domain IDs rely on the WWN. The WWN manager, a process-level manager residing
on the switch's supervisor module, assigns WWNs to each switch.
Cisco MDS 9000 Family switches support three network address authority (NAA) address formats (see
Table
Table 30-1
NAA Address
IEEE 48-bit address
IEEE extended
IEEE registered
OL-18084-01, Cisco MDS NX-OS Release 4.x
– The global fctimer values are not distributed.
Do not configure global timer values when distribution is enabled.
D_S_TOV E_D_TOV
5000 ms 2000 ms
F_S_TOV D_S_TOV
5000 ms 5000 ms
30-1).
Standardized NAA WWN Formats
NAA Type
Type 1 = 0001b
Type 2 = 0010b
Type 5 = 0101b
R_A_TOV
10000 ms
E_D_TOV R_A_TOV
3000 ms 10000 ms
WWN Format
000 0000 0000b
Locally assigned
IEEE company ID: 24 bits
Cisco MDS 9000 Family CLI Configuration Guide
World Wide Names
30-12 and
48-bit MAC address
48-bit MAC address
VSID: 36 bits
30-9
