Chapter 15 Configuring Generation 2 and Generation 3 Switching Modules
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m
Port rate modes are not supported on the Cisco Fabric Switch for HP c-Class BladeSystem, and the Cisco
Note
Fabric Switch for IBM BladeCenter.
Table 15-3
Table 15-3
Part Number
Generation 3 Modules
DS-X9248-96K9
DS-X9224-96K9
DS-X9248-48K9
Generation 2 Modules
DS-X9148
DS-X9124
DS-X9304-18K9
(MSM-18/4
Multiservice
module)
DS-X9112
DS-X9704
Generation 2 Switches
DS-C9134-K9
(Cisco MDS 9134
Fabric switch)
OL-18084-01, Cisco MDS NX-OS Release 4.x
shows the modules that support dedicated, shared, and the default rate modes.
Port Rate Mode Support on Generation 2 and Generation 3 Modules and Switches
Product Name/
Description
48-Port 8-Gbps Fibre
Channel switching module
24-Port 8-Gbps Fibre
Channel switching module
4/44-Port 8-Gbps
Host-Optimized Fibre
Channel switching module
48-port 4-Gbps Fibre
Channel switching module
24-port 4-Gbps Fibre
Channel switching module
18-port 4-Gbps Fibre
Channel switching module
with 4-Gigabit Ethernet
ports
12-port 4-Gbps Fibre
Channel switching module
4-port 10-Gbps Fibre
Channel switching module
32-port 4-Gbps Fabric
switch
2-port 10-Gbps Fabric
switch
Port Groups and Port Rate Modes
Supports Supports
Dedicated Rate Shared Rate
Mode Mode
1
Yes Yes
1
Yes Yes
1
Yes Yes
Yes Yes
2
Yes Yes
Yes Yes
Yes No
Yes No
Yes Yes
Yes No
Cisco MDS 9000 Family CLI Configuration Guide
Default Speed
Mode and Rate
Mode on All Ports
Auto, Shared
Auto, Shared
Auto Max 4 Gbps,
Shared
Auto, Shared
Auto, Shared
Auto, Shared
Auto, Dedicated
Auto, Dedicated
Auto, Shared
Auto, Dedicated
15-5
