JUNOSe 11.1.x Policy Management Configuration Guide
FPGA hardware classifiers are supported on all line modules except the OC48/STM16,
GE-2, and GE-HDE line modules. Table 18 on page 161 lists the FPGA classifiers and
software classifiers supported for each interface type.
An E Series router supports two versions of policies that are based on FPGA hardware
classifiers. One version has a maximum of 16 classifier entries per policy, and the
second version has 17 to 32 classifier entries per policy. The line module supports
16,255 policies when all policies have 16 hardware classifier entries or fewer, and
supports 8127 policies when all policies have 17 to 32 hardware classifier entries.
You can configure a combination of the two versions of FPGA hardware
classifier-based policies you can have some that contain 16 or fewer classifier entries
and others with more than 16 entries. In this case, between 8127 and 16,255 policies
are supported, depending on the actual configuration.
You can also configure hardware classifier-based policies that have more than 32
classifier entries. The router groups the classifiers into blocks of 32. For example, if
you configure a policy with 100 classifier entries, the router groups these as 3 policies
that have 32 classifier entries and 1 policy with 4 classifier entries. The group with
4 classifier entries actually consumes 16 classifier resources, which is the minimum
number consumed for a group in a mixed-mode hardware classifier configuration.
Unlike policies that are based on software classifiers, policies that are based on FPGA
hardware classifiers consume resources at a rate of one resource per policy, regardless
of the number of different hardware classifier categories in the policy. For example,
if a classifier list has three hardware classifiers, such as destination address, source
address, and protocol, the policy referencing that classifier list consumes only a single
hardware classifier resource.
The same is true when multiple policy rules reference the classifier list. For example,
if four policy rules reference the same classifier list (which contains three hardware
classifiers), then still only one classifier entry is consumed.

CAM Hardware Classifiers Overview

Content-addressable memory (CAM) hardware classifiers are supported on the
OC48/STM16, GE-2, ES2 4G, ES2 10G, ES2 10G Uplink, and GE-HDE line modules.
Table 17 on page 160 lists CAM hardware classifiers and the software classifiers
supported for each interface type.
The OC48/STM16 line module supports 128,000 144-bit CAM entries, and the GE-2
and GE-HDE line modules support 64,000 144-bit CAM entries. The ES2 4G LMs on
E120 and E320 routers support 256,000 144-bit CAM entries, and the ES2 10G and
ES2 10G Uplink LMs on E120 and E320 routers support 128,000 144-bit CAM entries.
For most configurations, each classifier entry in a policy consumes one CAM entry.
However, a policy that has only the default classifier consumes no CAM resources.
In this example, the policy consumes a total of four CAM entries: two entries for
clacl1, one for clacl2, and one for the default classifier.
162
CAM Hardware Classifiers Overview
host1(config)#ip classifier-list clacl1 ip host 192.168.1.1 host 192.168.2.2 tos 1
host1(config)#ip classifier-list clacl1 ip host 192.168.1.1 host 192.168.2.2 tos 2
host1(config)#ip classifier-list clacl2 tcp any any tcp-flags "SYN"
