JUNOSe 11.1.x Policy Management Configuration Guide
Table 16: Shorthand Notation Mapping (continued)
Shorthand
number Shorthand
5 SVLAN
6 FR-VC
7 ATM
8 Forwarding
9 ppp-interface
Hierarchical Aggregation Nodes
An internal parent group configured within a policy defines a hierarchical aggregation
node template. An attachment of this policy creates an aggregation node for each
internal parent group in a policy. Aggregation nodes are scoped within a single
attachment and cannot be shared beyond a single attachment. An aggregation node
stores a single rate-limit instance and statistics for this rate-limit. Aggregate nodes
can be shared between two or more classified flows within a single attachment using
the classifier group and parent group association.
Rate-limit aggregation nodes extend beyond a single attachment so classified flows
across two or more attachments can reference the same aggregation node to share
a single rate-limit instance. You can use external parent groups and policy parameters
for sharing aggregate nodes across policy attachments. Each external parent group
reference in a policy is accompanied by a parameter that is resolved during the
attachment of the policy to an interface. An external rate-limit aggregation node can
be defined by the 4-tuple (slot, direction, external parent group name, parameter
value). The slot is the logical number of the line module location and the direction
can be ingress or egress at the line module.
When you use hierarchical aggregation nodes, be aware of the following:
132
Hierarchical Aggregation Nodes
Value
Identifier constructed from slot, adapter, port,
SVLAN ID.
Unique identifier of frame relay minor interface
Unique identifier of ATM major interface
Unique identifier of the forwarding interface where
the parameter is configured.
Identifier constructed from PPP interface.
VR/VRF The hierarchical aggregate nodes based on external parent groups are
not virtual router sensitive. The configuration allows interfaces from different
virtual routers to have the same parameter name to value mapping, in which
case both interfaces could share the same aggregate node created by an external
parent group.
Direction of Traffic Hierarchical aggregate nodes are direction sensitive. The
configuration does not allow input and output traffic at an interface to share the
same rate-limit instance. Even when the input and output policy attachments
refer to the same external parent group and parameter value, two separate
aggregate nodes are created for each direction.
Line Module You should use hierarchical aggregate nodes. Rate limits cannot
be shared across different line modules or service modules. Even when you
configure the same parameter name to the same value for an external parent
Supported in
IP, IPv6, L2TP, and MPLS policies
IP, IPv6, and MPLS policies
IP, IPv6, and MPLS policies
IP, IPv6, L2TP, and MPLS policies
IP, IPv6 policies
